Uses of flat label applicator: Realize automatic attachment of self-adhesive labels on the flat surface of the product;
Function of labeling systems: Improve the efficiency of product labeling, with accurate location, good quality, and high stability; avoid manual labeling, effectively reduce product cost and enhance product competitiveness.
Application for best labeler machine:
Applicable labels: self-adhesive labels, self-adhesive films, electronic supervision codes, bar codes, etc .;
Applicable products: products that require labels to be attached to flat surfaces;
Application industry: widely used in food, toys, daily chemical, electronics, medicine, hardware, plastics and other industries;
Working principle for Automatic flat labeling machine:
The sensor detects the passing of the product, and returns a signal to the labeling control system. The control system controls the motor to send the label at the appropriate position and attach it to the product to be labeled. The product flows through the labeling device, the label is rolled, and a label The attachment action of is completed
Technical parameters:
Production(pcs/min) | 30-150 |
Driving Mode | Servo motor |
The way of labeling | top labeling |
Conveyor speed | ≤40 (m/min) |
Label Specification | adhesive sticker,transparent or opaque label(can be customized) |
The application of objects | customizing |
The application of label | Height 20-70mm Length 25-120mm (can be customized) |
The inner diameter of label roll | 76mm |
The outer diameter of label roll | 350mm(max) |
Power of motor (w) | 500W |
Power supply | AC220V 50/60HZ Single phase |
Dimension (mm) | 2200 (L) 900 (W) 1600 (H) mm |
About Packing：
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by misoperation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
Uses of flat label applicator: Realize automatic attachment of self-adhesive labels on the flat surface of the product;
Function of labeling systems: Improve the efficiency of product labeling, with accurate location, good quality, and high stability; avoid manual labeling, effectively reduce product cost and enhance product competitiveness.
Application for best labeler machine:
Applicable labels: self-adhesive labels, self-adhesive films, electronic supervision codes, bar codes, etc .;
Applicable products: products that require labels to be attached to flat surfaces;
Application industry: widely used in food, toys, daily chemical, electronics, medicine, hardware, plastics and other industries;
Working principle for Automatic flat labeling machine:
The sensor detects the passing of the product, and returns a signal to the labeling control system. The control system controls the motor to send the label at the appropriate position and attach it to the product to be labeled. The product flows through the labeling device, the label is rolled, and a label The attachment action of is completed
Technical parameters:
Production(pcs/min) | 30-150 |
Driving Mode | Servo motor |
The way of labeling | top labeling |
Conveyor speed | ≤40 (m/min) |
Label Specification | adhesive sticker,transparent or opaque label(can be customized) |
The application of objects | customizing |
The application of label | Height 20-70mm Length 25-120mm (can be customized) |
The inner diameter of label roll | 76mm |
The outer diameter of label roll | 350mm(max) |
Power of motor (w) | 500W |
Power supply | AC220V 50/60HZ Single phase |
Dimension (mm) | 2200 (L) 900 (W) 1600 (H) mm |
About Packing：
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by misoperation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
