Specifications:
1.Easy operation, Easy printing.
2.High accuracy,high quality and high speed
3.Low Price
Application:
This machine can be used for beer, wine and other glass bottles, PVC or pet bottle glue label; it is easy to operate and to connect to other production lines. Adopting stainless steel
materials make the production process more environmental and healthy.The using of advanced technology makes the labeling machine more effective and accurate.
1. Applicable label: Paper label (without paste, the paste will daub by the machine).
2. Applicable product: Required to be labeled on the Circumference of surface or other Curved surface.
3. Application industry: Food and beverage, chemical industry, pharmaceutical industry, wine bottles
4. Application examples: Canned food bottles, wine bottles, glass bottles, PVC bottles, vial and other special shaped bottles, according to customer's requirements
Features:
1). --Adopt imported electromagnetic clutch with best accuracy.
2). --The machine shell adopts high class aluminum alloy anodic treatment, with long life span service.
3). --Adopt famous factory electric motor to ensure high load and long period operation.
4). --All parts and standard components are carefully made of stainless steel.
5). --With PLC control panel, liquid crystal display, the operation is simple and convenient, the function is stable.
6). --Imported label inspection optical coupler can ensure high precision.
7). --There is a code printer on the machine if you need, it also can print three lines like the expire date, valid date, batch number
Characters:
Wet glue labeling machine can be equipped with the production line and can be stand-alone production too. Easy to operate, just turn the power on, gently click the start button, the entire device will enter the production status, the labeling of products via to get bottle, divided bottle, induction start signal, to send front label, to send back label, suction the front label, suction back label, marked on the front label, the back label, and finish the entire production process. Accurate, fast, are the features of this product.
Main technical parameters:
Operating direction | Left or Right |
Labeling Accuracy | ±1.0 mm(subject to the roughness of the plane) |
Production(bottle/min) | 30-80BPM(according to the size of bottle and label) |
The application of bottle | Outer diameter 40-100mm Height 35-200mm(can be customized according to customer’ requirement) |
The application of label | Width 8-150mm ; Length 20-280mm(can be customized according to customer’ requirement) |
The power of motor(w) | 1KW |
Voltage | AC220V 50/60HZ Single phase |
Size appearance(mm) | 2500(L) 900(W) 1270(H)mm |
How to use the machine
Video 2
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
After-sale service:
1. Instruction for Installation and Debugging
Before delivery, we takes responsible for debugging of machine, in order to make sure the provided machine could be safely and smoothly put into operation.
We also take responsibility to have debugging overseas, and Client abroad please sends invitation forward of time to engineer, provides the engineer with round-trip tickets, accommodation, vehicle and $50 per day salary.
2. User Training
Before delivery, we will take responsibility to indoctrinate technical training to the users so that they could understand the machine features and could operate the machine by themselves.
3. Warranty Period
The warranty period for machine is one year with a life long maintenance. If the user requires special quality guarantee, other stipulated warranty period may be made after mutual agreement.
Specifications:
1.Easy operation, Easy printing.
2.High accuracy,high quality and high speed
3.Low Price
Application:
This machine can be used for beer, wine and other glass bottles, PVC or pet bottle glue label; it is easy to operate and to connect to other production lines. Adopting stainless steel
materials make the production process more environmental and healthy.The using of advanced technology makes the labeling machine more effective and accurate.
1. Applicable label: Paper label (without paste, the paste will daub by the machine).
2. Applicable product: Required to be labeled on the Circumference of surface or other Curved surface.
3. Application industry: Food and beverage, chemical industry, pharmaceutical industry, wine bottles
4. Application examples: Canned food bottles, wine bottles, glass bottles, PVC bottles, vial and other special shaped bottles, according to customer's requirements
Features:
1). --Adopt imported electromagnetic clutch with best accuracy.
2). --The machine shell adopts high class aluminum alloy anodic treatment, with long life span service.
3). --Adopt famous factory electric motor to ensure high load and long period operation.
4). --All parts and standard components are carefully made of stainless steel.
5). --With PLC control panel, liquid crystal display, the operation is simple and convenient, the function is stable.
6). --Imported label inspection optical coupler can ensure high precision.
7). --There is a code printer on the machine if you need, it also can print three lines like the expire date, valid date, batch number
Characters:
Wet glue labeling machine can be equipped with the production line and can be stand-alone production too. Easy to operate, just turn the power on, gently click the start button, the entire device will enter the production status, the labeling of products via to get bottle, divided bottle, induction start signal, to send front label, to send back label, suction the front label, suction back label, marked on the front label, the back label, and finish the entire production process. Accurate, fast, are the features of this product.
Main technical parameters:
Operating direction | Left or Right |
Labeling Accuracy | ±1.0 mm(subject to the roughness of the plane) |
Production(bottle/min) | 30-80BPM(according to the size of bottle and label) |
The application of bottle | Outer diameter 40-100mm Height 35-200mm(can be customized according to customer’ requirement) |
The application of label | Width 8-150mm ; Length 20-280mm(can be customized according to customer’ requirement) |
The power of motor(w) | 1KW |
Voltage | AC220V 50/60HZ Single phase |
Size appearance(mm) | 2500(L) 900(W) 1270(H)mm |
How to use the machine
Video 2
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
After-sale service:
1. Instruction for Installation and Debugging
Before delivery, we takes responsible for debugging of machine, in order to make sure the provided machine could be safely and smoothly put into operation.
We also take responsibility to have debugging overseas, and Client abroad please sends invitation forward of time to engineer, provides the engineer with round-trip tickets, accommodation, vehicle and $50 per day salary.
2. User Training
Before delivery, we will take responsibility to indoctrinate technical training to the users so that they could understand the machine features and could operate the machine by themselves.
3. Warranty Period
The warranty period for machine is one year with a life long maintenance. If the user requires special quality guarantee, other stipulated warranty period may be made after mutual agreement.
