YQBC-100
YQ
Introduction:
It is mainly composed of a bottle clamping belt, a conveyor belt, and a water-gas cleaning structure. It can be used in a matching filling line or used for bottle washing alone. After the sanitary pump is pressurized, water is injected for the washing process, and the spray tube is inserted into the bottle to flush the air to complete the water washing and air washing process. This bottle cleaning machine has the characteristics of easy replacement and high cleanness of the bottle. It is suitable for various containers of different shapes, and can be used to sterilize, clean and blow dry glass/plastic bottles and jars. Convenient operation, simple maintenance, simple adjustment of bottle type changes, no need to change parts, is an ideal cleaning machines used in food, pharmaceutical, daily chemical and other industries.
Technical parameter:
Bottle washing capacity:4000-6000 bottles per hour
Water spray pressure: 0.2-0.8MPa
Air pressure: 0.6-0.8Mpa
Air consumption: 0.3m3/min
Bottle flushing time: 1.5 seconds
Water consumption: 2-4T/H
Total equipment weight: about 1500Kg
Dimensions: (L) 4200 × (W) 1400 × (H) 2000 mm
Total power: 7.4kw
About packing
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our service
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by wrong operation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
Introduction:
It is mainly composed of a bottle clamping belt, a conveyor belt, and a water-gas cleaning structure. It can be used in a matching filling line or used for bottle washing alone. After the sanitary pump is pressurized, water is injected for the washing process, and the spray tube is inserted into the bottle to flush the air to complete the water washing and air washing process. This bottle cleaning machine has the characteristics of easy replacement and high cleanness of the bottle. It is suitable for various containers of different shapes, and can be used to sterilize, clean and blow dry glass/plastic bottles and jars. Convenient operation, simple maintenance, simple adjustment of bottle type changes, no need to change parts, is an ideal cleaning machines used in food, pharmaceutical, daily chemical and other industries.
Technical parameter:
Bottle washing capacity:4000-6000 bottles per hour
Water spray pressure: 0.2-0.8MPa
Air pressure: 0.6-0.8Mpa
Air consumption: 0.3m3/min
Bottle flushing time: 1.5 seconds
Water consumption: 2-4T/H
Total equipment weight: about 1500Kg
Dimensions: (L) 4200 × (W) 1400 × (H) 2000 mm
Total power: 7.4kw
About packing
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our service
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by wrong operation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
