YQPF-1
YQ
Features:
The filling speed is faster than 4-head and 6-head filling machine. The whole machine is controlled by a servo motor, liquid, cream and paste are compatible. Single-head fast filling machine, breaking through the traditional filling method. The positioning fiber imported from Germany, the whole machine is made of stainless steel 304. It has the advantages of precise filling, one-key cleaning, small footprint, multi-purpose machine, and strong stability.
Advantages:
1) Long life span
2) Controlled by servo motor
3) Widely application
4) Easy to operate
5) Can be equipped with automatic feeding function
6) Easy to clean
7) Small footprint
8) High speed filling
9) Stable
Application field
The high speed single head filling machine is widely used for cosmetic, food, pharmaceutical, chemical industry and etc...It is suitable for all kinds of liquid, paste, cream, essential oil, laundry detergent, shampoo, shower gel, honey etc.
Technical parameter
Capacity | 6000 bottles/h |
Net weight | 200kg |
Filling volume | ≥5g |
Filling head | Single head |
Suitable bottle diameter | 10-180mm(can be customized) |
Suitable bottle height | 30-223mm(can be customized) |
Filling accuracy | ±0.3% |
Dimension | 2200*800*1200mm |
Filter
Airtac filter makes the air pressure more stable. The water vapor generated by the air compressor in the application process is automatically discharged to ensure that the normal operation accuracy of the air pressure of the machine reaches two thousandths.
PLC touch screen
Make adjustments according to different products. Color interface, switch between Chinese and English, easy to operate
Servo conveyor
The conveyor is controlled by servo motor. Stable operation, bottles do not fall down, abrasion resistance, strong bearing capacity.
Switch control
Lights up when working, emergency stop switch
Configuration list
Sensors | SICK |
Servo drive | HCFA |
Servo motor | HCFA |
Pneumatic configuration | Air TAC |
Touch screen | HCFA |
Electromagnetic valve | Air TAC |
Relay | Schneider |
Filling nozzle | Single head |
Filling volume | No limit |
PLC | HCFA |
Material | SS304 |
Filling speed date
30-50g | 60-140 bottles/min |
100-300g | 45-120 bottles/min |
500-1000g | 35-80 bottles/min |
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
After-sale service:
1. Instruction for Installation and Debugging
Before delivery, we takes responsible for debugging of machine, in order to make sure the provided machine could be safely and smoothly put into operation.
We also take responsibility to have debugging overseas, and Client abroad please sends invitation forward of time to engineer, provides the engineer with round-trip tickets, accommodation, vehicle and $100 per day salary.
2. User Training
Before delivery, we will take responsibility to indoctrinate technical training to the users so that they could understand the machine features and could operate the machine by themselves.
3. Warranty Period
The warranty period for machine is one year with a life long maintenance. If the user requires special quality guarantee, other stipulated warranty period may be made after mutual agreement.Mechanical models are standard, make special design according to customer requirements.
