YQTF-500
YQ
A. Inline filling machine
Introduction:
This high speed filler is suitable for filling various liquids, pastes, sauces (shampoo, shower gel, hand soap, laundry detergent, etc.), with strong versatility.
Features:
1. Piston/ flow meter controlling,high filling accuracy,±0.5%
2. Key components are made in high quality stainless steel,and compliant to GMP.
3. Filling heads 6/8/12/16, filling speed 4000~8000 bph
4. Filling nozzles can be controlled respectively or as a whole by the servo motor
5. Anti-leak,anti-foaming design for filling
6. CIP system,easy to clean the tank and the filling system
7. Steady pressure system for the material tank(optional according to the actual condition)
8. PLC controlled,friendly HMI operation interface,Chinese-English bilingual
Technical Parameters:
(1) Machine dimension: 2000mm(L)* 1200mm(W)*2500mm(H)
(2) Filling heads:Accorting to production capacity
(3) Filling range: Customized
(4) Diameter of bottle mouth: Customized
(5) Production capacity: 6000b/h(take 750ml foamy product as test) for 16 filling heads
(6) Filling Tolerance: Filling machine for volume ≤500ml----±1g
Filling machine for volume ≥500ml----±2g
(7) Power supply: AC380V,50Hz; AC220V,50Hz (customized)
(8) Air consumption:0.55-0.65 Mpa clean and stable compressed air
B. Capping Machine
Introduction:
This high speed rotary capping machine is with cap sorting bowl and cap feeder system ,dispatches caps in high speed with no reverse caps which can be suitable for various types of bottles.
The cap supplying system and the manipulator works at the same step. When caps capped well , the bottes and the caps are relative static ,the clutch releases ,this can avoid bottles getting injured to achieve high qualified rate of capping. The surface of machine is made of high quality stainless steel ,the eletrcial elements use international famous brand which makes machine more stable ,good-looking meets GMP standard
Features:
1. Four wheels structure, which is suitable for round caps, pump caps, duck mouth caps, trigger caps with straw.
2. PLC controlled ,integrated cap sending ,grasping ,capping ( can affiliate with automatic cap sorter)
3. Automatic inlet cap and bottle position-setting and orientation, adjustable torque control.
4. Gentle manipulation, no scratch and injury to caps and containers
5. Easy changeovers, one line capable of several products
6. Connected with filling machine and labeling machine easily
7. Module structure, manipulate on the touch screen, easy maintenance
8. Suitable for containers made of PET/PP/PE/HDPE and so on
9. Production capacity can achieve 4000-8000b/h, higher speed can be customized.
Technical Parameters:
Machine Dimension(L*W*H):2m*1.4m*2.6m | Air operated source: 0.6Mpa clean and stable compressed air |
Suitable caps : can be customized | Diameter of pump cap: can be customized |
Power suply: AC 380V, 50Hz | Number of capping heads:4/8/12 |
Length of pump cap: shorter than 250mm | Weight: 2500Kg |
Machine power:4Kw(8 capping heads) | Torque control: around 0.3 Nm |
Capacity: | About 3000 BPH(4 heads) About 5000 BPH(8 heads) About 7000 BPH(12 heads) |
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by wrong operation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
