1.Dual frequency conversion control, bag length can be setted and cutting in one step,saving time and films.
2.Interface features are easy and quick setting and oprating.
3.Self diagnosis failure function, clear failure display.
4.High sensitivity photoelectric eye color tracing,numerical input of cutting sealing position for extra accuracy.
5.Temperature independent PID control, suitable for packing different materials.
6.Positioned stop function,without sticking knife or wastingfilm.
7.Simple driving system,reliable working,convenient maintenance.
8.All control is realized through software,easy for function adjusting and technical upgrade.
Packaging various kinds of regular objects like biscuits,pies,chocolates,bread,instant noodles,moon-cakes,drugs,daily applications,industrial parts,paper boxes,tray,etc.
Technical Info:
Type YQ-250 YQ-320 YQ-350 YQ-400
Film width 250MM 320MM 350MM 400MM
Bag Length 45-280MM 65-330MM 65-3300MM 150-400MM
Bag width 30-110mm 50-160MM 50-160mm 50-180mm
products Hight max.55mm Max.55mm Max.60mm Max.65mm
Speed 40-230bag/mins 40-230bag/min 40-180bag/min 30-150bag/min
Power 220V 50/60HZ
Size(mm) 3770x670x1450 3770x720x1450 4020x770x1450 4020x800x1450
Weight 500kg 550kg 580kg 600kg
After-sale service:
1. Instruction for Installation and Debugging
Before delivery, we takes responsible for debugging of machine, in order to make sure the provided machine could be safely and smoothly put into operation.
We also take responsibility to have debugging overseas, and Client abroad please sends invitation forward of time to engineer, provides the engineer with round-trip tickets, accommodation, vehicle and $100 per day salary.
2. User Training
Before delivery, we will take responsibility to indoctrinate technical training to the users so that they could understand the machine features and could operate the machine by themselves.
3. Warranty Period
The warranty period for machine is one year with a life long maintenance. If the user requires special quality guarantee, other stipulated warranty period may be made after mutual agreement.Mechanical models are standard, make special design according to customer requirements.
1.Dual frequency conversion control, bag length can be setted and cutting in one step,saving time and films.
2.Interface features are easy and quick setting and oprating.
3.Self diagnosis failure function, clear failure display.
4.High sensitivity photoelectric eye color tracing,numerical input of cutting sealing position for extra accuracy.
5.Temperature independent PID control, suitable for packing different materials.
6.Positioned stop function,without sticking knife or wastingfilm.
7.Simple driving system,reliable working,convenient maintenance.
8.All control is realized through software,easy for function adjusting and technical upgrade.
Packaging various kinds of regular objects like biscuits,pies,chocolates,bread,instant noodles,moon-cakes,drugs,daily applications,industrial parts,paper boxes,tray,etc.
Technical Info:
Type YQ-250 YQ-320 YQ-350 YQ-400
Film width 250MM 320MM 350MM 400MM
Bag Length 45-280MM 65-330MM 65-3300MM 150-400MM
Bag width 30-110mm 50-160MM 50-160mm 50-180mm
products Hight max.55mm Max.55mm Max.60mm Max.65mm
Speed 40-230bag/mins 40-230bag/min 40-180bag/min 30-150bag/min
Power 220V 50/60HZ
Size(mm) 3770x670x1450 3770x720x1450 4020x770x1450 4020x800x1450
Weight 500kg 550kg 580kg 600kg
After-sale service:
1. Instruction for Installation and Debugging
Before delivery, we takes responsible for debugging of machine, in order to make sure the provided machine could be safely and smoothly put into operation.
We also take responsibility to have debugging overseas, and Client abroad please sends invitation forward of time to engineer, provides the engineer with round-trip tickets, accommodation, vehicle and $100 per day salary.
2. User Training
Before delivery, we will take responsibility to indoctrinate technical training to the users so that they could understand the machine features and could operate the machine by themselves.
3. Warranty Period
The warranty period for machine is one year with a life long maintenance. If the user requires special quality guarantee, other stipulated warranty period may be made after mutual agreement.Mechanical models are standard, make special design according to customer requirements.
