Introduction:
Cosmetics tubes are one of the most challenging products to label well. Not only are they small and difficult to align, they also come in so many variations of color and style. This horizontal tube labeling system is made specifically for handling small and fragile products. This bottom labeling system can handle products that in small diameter, sizes that are typical of cosmetics products alone. It uses two gentle guides to hold products steady as they approach the label head.
Optional functions:
①Hot coding/printing function ②Automatic receiving function (combined with product consideration) ③Add labeling head ④Other functions (customized according to customer requirements)
Working process
The main working principle: Put the product on the conveyor belt, the sensor detects the product passing, and sends back a signal to the labeling control system. At the appropriate position, the control system controls the corresponding motor to send out the label. The cylinder drives the suction nozzle to pick up the label and attach it to the product. At the labeling position, the attaching action of a label is completed; Operation process: put the product (put it in the blanking box) —> separate the product and put it on the conveyor belt (automatically realized by the equipment) —> product conveying (automatically realized by the equipment) ) —> Labeling (automatically realized by equipment) —> Collect labeled products.
Technical parameter
The following are the technical parameters of the standard model, and other special requirements and functions can be customized.
Labeling accuracy | ±1mm |
Labeling speed | 20~50 pcs/min(It depends on product); |
Product size | ¢12≤diameter≤¢39mm(Specific according to the sample provided) |
Label size | 10≤width≤20mm,10≤length≤20mm; |
Dimension | 2000×1200×900mm |
Power | 220V 50/60HZ |
Net weight | 200Kg |
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by misoperation.After the guarantee period, the Seller will supply all the parts that the User need for the
