Introduction:
YQ machinery hot fill bottle filler can fill a wide range of products and handle a wide variety of container sizes and shapes. Applications include candles, deodorant, petroleum jelly, lip balm, shoe polish, glycerin soaps, cosmetic pencils, stick foundations and many others.
The fill heads are adjustable to accommodate a wide range of container sizes. Accurate and consistent filling is achieved using PLC controlled bottle movement and fill control. Its compact design requires minimal floor space and operates more efficiently, and the robust stainless steel construction provides years of durability.
Our hot filling machine has these functions of self-contained heating system, PLC operator controls, anti-drip filling nozzles, and independent heating controls.These are only just a few reasons why this YQ machinery can stand above the competition.
Features:
1. This hot fill bottling machine is composed of multiple heads servo piston heating filling machine,freezing tunnel, temperature recovery and preson capping/screw capping machines.
2. Double-shell tanks with heating device can ensure that the raw materials are heated evenly. With PID temperature control, tolerance within mini Celsius error.The pump and filling nozzle are independently heated, and there is no heating dead angle.
3. The piston pump is driven by the servo motor, and the quantitative and precise filling is more stable and fast; the low noise makes the production environment more comfortable.
4. Using PLC program control, the hot fill bottle filler machine operation is simpler and easier to learn.
5.The fill heads are adjustable to accommodate a wide range of container sizes. Accurate and consistent filling is achieved using PLC controlled bottle movement and fill control. Its compact design requires minimal floor space and operates more efficiently.
Production operation process:
Place bottle into mold manually →Heat Filling→Frozen →Rewarmed →Place cap manually/automatically→Press on capper/Screw capping
Technical Parameters
Power supply voltage | 380V/50HZ |
Installation requirements | 380V power supply, air source, 35kg heat transfer oil |
stirring speed | 0~90 rpm |
filling machine power | 5.5KW |
Refrigeration compressor power | 3.5KW 5P(The power of the whole machine is 4.2KW) |
Circulation line in the tunnel | multiple lines |
Filling machine line | 2 meters adjustable speed |
filling hopper volume | 50L |
production capacity | 30-100pcs/min(Related to filling amount and recipe) |
The whole machine size | 8000mm*1200mm*1700mm |
Freezer size | 2500*1000*1500mm |
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by wrong operation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
