Availability: | |
---|---|
Quantity: | |
YQIC-1
YQ
Introduction:
If you need to incline or decline a product to match a production line or provide ergonomic support to an employee, YQ MACHINERY incline conveyor systems can provide the necessary flexibility. Our incline conveyors can come equipped with horizontal sections, infeed, and/or outfeed to provide better product handling and controls. mk incline conveyors are also ideal in hopper applications or feeding parts into bowl feeders.
This stainless steel incline conveyor is equipped with washdown rated motors, drives, and supports making it perfect for transporting different material. The example model shown has an incline of different degrees and infeed and discharge heights of ranges 1800-4500mm.
Frame Package
All frame components are made from stainless steel including bed, side frames, spreaders, fasteners, take-up frames & adjusters, side skirts, brackets and all guards.
Drive Package
Wash down motor, reducer, chain, sprockets, keys, fasteners, rod ends & threaded rod (if shaft mounted reducer).
Roller/Pulley Package
Pulleys, pulley axles, spacers, take-up frame bearings, any flange or pillow block bearings, return or curve rollers, axles & fasteners are all stainless steel
Support Package
Includes stainless legs, knee braces, mounting brackets, fasteners & feet.
Technical specification
Model | YQIC-1 |
Convey Height | 1800-4500 mm |
Belt Width | 220-400 mm |
Bucket Material | White PP (Food grade) |
Vibrator Hopper Size | 650L×650W mm |
Power supply | 220V/50HZ or 60HZ Single Phase, 0.75KW |
Gross Weight | 150kg |
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by misoperation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
