YQCS-60
YQ
Inline Capper Introduction:
The Spindle capping machine is specifically designed to handle various size caps from bulk, orient, place them on a container, and screw them at a predetermined torque. This spindle capper comes equipped with our cap sorter and elevator(optional). “anti-cock” cap stabilizer, heavy duty quill clutches, and control panel and the complete safety guards are all standard.
Inline Capping Machine Features:
1.Heavy duty 304 stainless steel welded frame for easy mounting over existing conveyors.
2.Heavy duty linear carriage system for height adjustability
3.All shafts and threaded rods manufactured in 304 stainless steel
4.No change of parts needed for a wide range of containers
5.Front covers with safety interlock switches standard
6.Adjustable height to accommodate containers from 1 inch to 14 inches tall\
7.Easy changeover for caps from 10mm to 100mm in diameter, with appropriate tooling
Sorter mounted on machine, no need for independent height adjustment
Technical Parameter
Power supply | AC220V / 50HZ,60HZ |
Power | 1.5KW |
Cap Diameter | 10-100mm |
Capping speed | 40-150bottles/min |
Suitable bottle height | 50~280mm |
Air sauce pressure | 0.6-0.8MPa |
Net Weight | 650kg |
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by wrong operation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
