YQTF-60
YQ
Introduction:
Metal tube filling and sealing machine is mainly used for quantitative filling and sealing. This tube filler is widely used in packaging in the pharmaceutical, daily chemical, food, chemical and other industries. Such as ointment, adhesive, AB glue, epoxy glue, skin cream, hair dye, shoe polish, toothpaste and other liquid or paste materials filling and sealing.
Work process:
Automatically feeding the metal pipe into the Indexing plate (16 stations), use mechanical transmission to automatically index, photoelectric detection, confirm that there is a tube and then start automatic metering and pouring into the tube, and then perform two-way four-fold sealing and finished product exit.
Key Features
Pneumatic tube washing feeding intelligent temperature control and cooling system.
316l stainless steel contact parts to meet GMP standard automated working process from tube loading to finished.
Technical parameter
model | YQTF-60 |
Power supply voltage (V / Hz) | AC 220/110V;50.60HZ(can be customized) |
Power (W) | 1.5kw |
Air source (Mpa) | 0.6-0.8 |
Filling range (Ml) | 3-30;5-75;30-200 |
Air consumption (m3 / min) | 0.3 |
Measurement accuracy | ±1% |
Production capacity (support / min) | 40-60 |
Overall dimensions (L × W × H) (mm) | 1800 × 900 × 1900 |
Net weight (kg) | 500 |
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by wrong operation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
