Introduction:
YQ machinery manufacture different self-adhesive labeling machines.We design and build high specification, high quality labeling equipment and has a range of standard and special purpose machinery. Our labeling machines with high-performance includes pressure sensitive labeler,round bottle labeling machines,one label for three sided label applicator etc.
Features:
1. Precise alignment devise ensures precise labeling position.
2. After label dispensing , label will be folded to side immediately to prevent wrinkle or bubbles.
3. Top hold down belt to keep bottles stay in the central part of conveyor while transferring.
4. Automatic bottle separator which can assures smooth bottle transportation one by one.
5. Conveyor belt with condensed design can be customized according to customers’container.
6. Pushing system automatically smoothes label to each side of the bottle.
7. Made of stainless steel for easy maintenance and longevity.
8. Label sensor precisely detects the location of labels and product and increases accuracy.
9. Driven by servo motor and the labeling height and angle can be adjusted by products.
Options:
-Transparent label sensor
-Date printer
-Inkjet printer
-feeding turntable/collecting table
Technical Parameter:
Speed: 40-60 pcs/min
Accuracy: ± 1 mm
Label size: ( L) 20-300 mm x (W) 10-100 mm
Total length for labeling: 20-300 mm
Label roll inner diameter: 75 mm
Outer diameter: 350 mm
Labeler dimension: ( L) 2400 mm x (W) 1200 mm x (H) 1500 mm
Power supply single phase: 110 or 220 VAC. 50/60 Hz(can be customized)
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by misoperation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
