Main Features:
1. It is a combination of mechanical and electrical, automatic feeding bag, clamp bag, filling, sealing and output.
2. One time sealing mode to avoid bag broken.
3. Easy to operate: PLC and color panel, easy operation.
4. Reasonable design, simple structure, running is more reliable.
5. Suitable for 3-side sealing bag, 4-side sealing bag, flat bag.
Options:
1.Gusset device: For making gusseted bag or block bottom bag.
2.Auto tracking device: For automatically regulation film position.
3.Date printer: To print code, one line or two lines, maximum 11 letters per one line.
4.Air expeller: Expel air from the bag to be finished.
5.Hole punch device: Pouch hole to handle bag.
6.Bag supporter: For big weight.
Application for bags
Technical Parameter:
Model | YQBZ-300D |
Bag Type | Pouch Bag , Gusseted pouch, Pillow Bag |
Bag Size | Standard Bag: 100-300mm(W) *100-350mm(L) Ziplock Bag: 130-300mm(W) *130-350mm(L) |
Speed | Max 15 BPM(up to product character) |
Power Supply | 220V/50HZ or 60HZ Single Phase 1KW |
Air Pressure | 7.0 CFM@80 PSI |
Operation Panel | 7 inch touch screen |
Electronic: | Mitsubishi PLC/ Omron Temperature Controller Omron Power Switch / Schneider Breaker |
Options | Zipper bag open device Product Settler Gas Flush Take Away Conveyors Filling Devices |
Other | Without other high power motive equipment around Keep away from sunshine, high temperature and wind. |
Weight | 320KG |
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
After-sale service:
1. Instruction for Installation and Debugging
Before delivery, we takes responsible for debugging of machine, in order to make sure the provided machine could be safely and smoothly put into operation.
We also take responsibility to have debugging overseas, and Client abroad please sends invitation forward of time to engineer, provides the engineer with round-trip tickets, accommodation, vehicle and $100 per day salary.
2. User Training
Before delivery, we will take responsibility to indoctrinate technical training to the users so that they could understand the machine features and could operate the machine by themselves.
3. Warranty Period
The warranty period for machine is one year with a life long maintenance. If the user requires special quality guarantee, other stipulated warranty period may be made after mutual agreement.Mechanical models are standard, make special design according to customer requirements.
