Control Panel
• Manual or Automatically Repetition Cycle Control System
Frame
• Durable All Stainless Steel 304 Construction to meet the current GMP Standard
Spare Parts and Accessories are Included
• New type acid resistance sealing ring (01 set)
• Material pipe Included
• Tools Included
Specifications & Accessories Included
• Single Head Piston Liquid Filler
• Adopting advanced pneumatic parts (Germany FESTO or Taiwan AIRTAC)
• Cylinder and Filling Nozzle made up of 316L stainless steel and polyethylene with Teflon, it accord with cGMP standard
• Filling range and filling speed can be adjust either by Auto mode or Manual
• Filling set adopts preventing leaking and preventing silk nozzle
• Liquid Hose Included
• Changeable nozzle tips
• Ex-proof model. Machine can operate without electricity-- only by compressed air (Pneumatic type only)
• Filling precision: > 99.5%
• Filling Range: YQ-500: 50-500ml, Ideal Filling Range: 100-500ml
Capacity
• Production Capacity: 15-22 Bottles per Minute
(Production Speed depending on the Operator’s skill)
Compressor Air
• Air pressure requirement: 0.4-0.5Mpa
• Air Consumption: 3-5 cfm
Power Source
• 110/220V 50HZ
Dimension
• Machine Dimension:YQ-500 Bench top type: 980x430x710mm
Weight
• Machine Weight: YQ-500 Bench top type: 45KG
Parameter
| Model | Filling Range | Ideal Filling Range | Filling Accuracy | Capacity (per minute) | Other Parameters |
| YQ-100 | 10~100ml 0.35~3.53oz | 20~100ml 0.71~3.53oz | ±5 ‰ | 20~38 | Power Supply: AC110/220,50Hz
Power: 25W
Air Supply: 0.4~0.5MPa
58~72.6psi
Air Consumption:
0.28 - 0.70m³/min |
| YQ-250 | 25~250ml 0.88~8.82oz | 50~250ml 1.76~8.82oz | ±5 ‰ | 18~30 |
| YQ-500 | 50~500ml 1.76~17.64oz | 100~500ml 3.53~17.64oz | ±5 ‰ | 15~22 |
| YQ-1000 | 100~1000ml 3.53~35.27oz | 200~1000ml 7.05~35.27oz | ±5 ‰ | 10~18 |
| YQ-2000 | 200~2000ml 7.05~70.55oz | 400~2000ml 14.11~70.55oz | ±5 ‰ | 7~13 |
| YQ-5000 | 500~5000ml 17.64~176.37oz | 1000~5000ml 35.27~176.37oz | ±5 ‰ | 5~8 |
