Feature:
1.Using the vacuum suction screw method, overcomes the characteristics that the wind blow screw can not send the length to diameter ratio of 1.2, and also overcomes the characteristics of the magnetic suction screw stainless steel screw can not suck, for the screw between M1.0-M4.0 Can be applied.
2.The screw feeder adopts the latest rotary disc type structure, the four-division small turntable sub-screw mechanism has small noise, the screw has high reliability, and the screw is maintenance-free. It can be applied. If the screw changes, just replace the nozzle. can.
3.The device control uses DPS + handheld programmer, the programming interface is friendly, the program can be copied and copied, very flexible, the internal storage is large, and can store up to 1000 sets of lock screw programs. One product only needs to be programmed once, after saving, It can be called when needed.
4.The interface can dynamically display the running status, and realize the status of the screw can monitor the lock screw in real time, can record each screw OK or NG.
5.The torque is accurate. Easy to adjust and ensure the quality of the lock.
Main technical parameters:
Input voltage | 110/220V | |
Working pressure | 0.3-0.6mpa | |
Production | 1-28kgf. Cm (optional) | |
Delivery speed | 40 capsules / minute | |
Applicable screw diameter | 2-6MM | |
Applicable screw length | 4-16 | |
Applicable nut diameter | 3.5-9 | |
Applicable screw | groove type, cross, etc. | |
Screw hole size | sink hole is less than 30 | |
Automatic screening | √ | |
Automatic replenishment | √ | |
Alarm function | √ | |
Counting function | √ | |
Torque size | 2-8KG/3-16KG | |
Hopper capacity | 2000 capsules |
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by wrong operation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
