YQCS-100
YQ
Specifications
1.automatic capping machine
2. suitable for caps of different shapes and sizes
3. high capping speed
Main application:
The Automatic Spindle Capper from Liquid Packaging Solutions is ideal for almost any packaging system. Automatic spindle capping machinery provides continuous capping for a wide variety of cap sizes, cap types, container sizes and container types! An automatic cap delivery system allows for continuous capping, making the spindle capper ideal for automated, inline packaging systems.
Products Information:
Machine applicable to the diameter 10 mm-100mm all kinds of bottle caps, overcomes the traditional screw cap machine a bottle with a set of star wheel, a cap with a covering of ills. This kind of novel and unique design, convenient operation and adjustment, the fastest production up to 150 bottles/minute. It can be used to single production, but also it’s the ideal models for the filling production line.
Main features:
1. Portable stainless steel construction
2. Cap sorting device and Cap chute
3. Adjustable gripper belts
4. Power height adjustment
5. Stainless steel face panel and lower base for easy cleanup
Technical Parameter
Power supply | AC220V / 50HZ,60HZ |
Power | 1.5KW |
Cap Diameter | 10-100mm |
Capping speed | 40-150bottles/min |
Suitable bottle height | 50~280mm |
Air sauce pressure | 0.6-0.8MPa |
Net Weight | 650kg |
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by wrong operation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
