YQTB-100
YQ
Introduction:
The top and bottom labeling machine is mainly suitable for labeling on flat surface of various products in the daily chemical, pharmaceutical, health care, food, chemical and other industries. Realize the automatic attachment of self-adhesive labels and self-adhesive films on the flat and small arc surface of the product.
Function:
1. Improve the efficiency of product labeling and film application,
2. Accurate application position, good quality, and high stability;
3. avoid manual labeling, low film efficiency, skewed application, blistering and wrinkles, irregular application positions, etc. Series of problems;
4. effectively reduce product costs, improve the aesthetics of product logos, and enhance product competitiveness.
Advantages:
1. The mechanical structure is micro-designed, occupies less space, and the equipment is easy to move and install in the assembly line;
2. Adopt the product guide gap elimination mechanism and the label anti-offset mechanism, and the label positioning accuracy is as high as ±1mm;
3. The labeling stability is good, the labeling is flat, wrinkle-free, and bubble-free, which can meet the requirements of labeling on most product flat and small arc surfaces;
4. The structured combination of mechanical adjustment parts and the ingenious design of label winding, easy to fine-tune the freedom of labeling position (fixed after adjustment), make the conversion between different products and label winding simple and time-saving;
5. It has the functions of nothing but no labeling, automatic correction and automatic detection when there is no label;
6. The main material of the equipment is 304 stainless steel, the overall structure is firm and beautiful;
7. It adopts standard PLC+touch screen+servo motor+standard sensor electric control system control, high safety factor, man-machine interactive interface with all English annotations and perfect fault handling prompt function, operation teaching function; easy to use and simple to maintain;
Technical Parameter:
Driving mode | Servo Motor | Output (pcs / min) | 20-130 |
Operating Direction | Left or right | Conveyor speed (m / min) | ≤35 |
Label roll inner diameter (mm) | 76mm | Label roll outer diameter (mm) | 350mm (max) |
Label Specifications | adhesive sticker | The application of carton | 30-300mm |
Labeling accuracy | ±1.0mm | Weight (kg) | 260 |
Total motor power | 1000W | Voltage | AC 220V/1P |
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by wrong operation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
