YQFC-20
YQ
Introduction:
YQ machinery supply tube filling machine for mascara and lip gloss.This type of filling and assembly machine can operate at speeds of up to 30 bottles per minute depending on the product to be filled. The Monoblock filler is compact in size, with easy access to all stations for service or changeovers. It uses a positive displacement cam driven piston pump with servo motor driven bottom-up fill nozzle (drip-proof nozzle).
Features
1. Put bottles manually/automatic(option)
2. Sensor detection:No bottle no filling
3. Automatic filling: piston pump filling, filling accuracy:±0.05g
4. Servo control piston, filling speed and metering are adjustable
5. The filling adopts two modes of filling and lifting and positioning filling to ensure that the nozzle is free from pollution
6. Feed inner plug automatically, press inner plug automatically.
7. Brush cap manually place to the linear guide and then place into bottle automatically(the cap with brush is easy to be scratched, by vibratory bowl)
8. Servo capping:Cap torque can be adjusted on the screen
9. The capping adopts 2 or 3 jaw mode, which will automatically return to zero after the capping is completed, which is convenient for the production of special-shaped caps.
10. 30L hopper
11. Rotary type: The speed can be adjusted
12. Gas-electricity separation design structure, power 3.0 KW
Advantage:
Stainless steel control box.
Power On-Off switch/circuit breaker.
Machine Stop and Start function key.
PLC machine controller (Brand name)
7” Color touchscreen HMI
Cap verification sensor
Emergency Stop switch.
Purge – Run mode switch.
Working process:
It includes bottle placing( automatically or manually), filling,inner plug pressing, wiper placing(automatic or manually), and cap / applicator placing and torquing.
Place bottles on the molds( automatically or manually) – Automatic filling(no bottle no filling) – Vibrating bowl to sort inner plug – Feed inner plug automatically/pressing plug–place the wiper on the linear guide(( automatically or manually))– Automatically cap applicator and torque– Bottle come out into conveyor automatica
Technical parameter:
Machine type | Rotary type |
Filling speed | 20-30 bottles/min |
Filling head | 1 head |
Filling method | Servo control |
Molds number | 16 pieces |
Hopper volume | 30L Pressure tank |
Operation staff | 2 persons |
Total power | 3KW |
Whole machine weight | 550kg |
Air pressure | 0.6Mpa |
Dimension | 1600*1500*1750mm |
Video Clip For Automatic Mascara Lip Gloss Filling Machine
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by misoperation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
