YQRF-100
YQ
Filling part
Introduction:
Rotary filling and capping machine adopts disc positioning filling and four-wheel capping, which is stable and reliable, with accuracy of over 99%. This machine uses high-precision closed cam indexing station, which has high precision, reliable operation and long service life. The indexer has a simple structure and can be used for long-term.
This filling machine is mainly suitable for filling and capping of various liquids, such as lotion, e-liquid, etc. Widely used in food, pharmaceutical, chemical industry and scientific research fields. This rotary filling machine is filled with advanced peristaltic pumps or stainless steel piston pumps with high filling accuracy. The bottle filling machine includes transmission parts, filling parts, capping parts etc. It has a compact structure, reasonable design and stable operation. long lasting.The filling machinery can not only stand alone production, but also form a linked production line with bottle washing machine, dryer and other equipment. Fully meet the national GMP requirements. This liquid filling machinery can upgrade the electrical configuration according to customer requirements.
Advantage of this bottling machine:
1.Man-machine interface setting, intuitive and convenient operation, PLC control, accurate loading.
2. Variable frequency control, arbitrary adjustment of production speed, automatic counting.
3. Automatic stop function, no bottle, no filling, no inner stopper.
4. Disc positioning filling, stable and reliable.
5. High-precision cam indexer control, accurate positioning.
6. Made of SUS304 and 316L stainless steel, fully comply with GMP requirements.
Technical Parameters:
Model | YQRF-100 |
power supply | 110/220V ,50/60Hz |
Power | 1.5 kw |
Loading range | 10-100ml (can be customized) |
Loading error | ≤ ± 1% |
Production capacity: | 20-30 bottles / minute |
Dimensions: | 1400 * 1600 * 1500mm |
Net weight of machine: | 300 kg |
Capping Part
Introduction:
This rotary capping machines can accommodate a range of container and cap sizes with minimal change parts. This makes them the perfect capper for customers or contract packagers who plan to run multiple products on a single bottling line. All cappers have color touch screen displays featuring a full management interface for complete efficiency control.
Advantage:
This Rotary Cappers can work with multiple type of Caps (Screw-on, Snap-on, Oriented Snap-on, Pilfer Proof), Trigger Pumps, Dosing Pumps and Caps with Dip Tube. Build as a stand-alone machines or integrated with other filling and capping modules in Rotary Monoblocks.
Technical parameter
Production capacity: 30-50 bottles/min
Power and voltage: 2kw, AC 380/220V; 50/60 hz
Air pressure: 0.6Mpa( clean and stable gas source)
Dimension mm: 950*800*1400(L * W * H)
Net weight of machine: 200kg
About Packing:
To ensure our service quality, we will execute the following packaging standards in delivery:
1.All the products before delivery should be tested by assemble and debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package.
2.In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading and uploading, the upward mark will be posted on the wooden case.
Our services:
A-The whole system
The Seller ensure the whole system can get to the requested capacity, accept and cooperate with the Buyer to pass the final testing of the whole system.
B-On-site installation:
The Seller supply the on site installation for the whole system, but the fees including air tickets, foods, hotel and translator in this period should be paid by User,the subsidy is 80USD/day.
C-Technical support:
The Seller supplies the technical support of the whole use life of the system,including the capping machine,and the procedures.
D-Spare parts supply:
The Seller should supply the quick-wear parts with the machine, to help the Buyer n further using. In the quality guarantee period, the Seller will supply the broken parts for free, except the easy worn parts or the damage is caused by wrong operation.After the guarantee period, the Seller will supply all the parts that the User need for the whole use life of the machine in cost price.
